PWM solar panel charge controller 10a 12v/24v

Features

1. 12V and 24V systems automatically identify.
2. Dual digital display more intuitive.
3. Increase in temperature compensation sensor, control more accurate, more

consistent battery temperature curve.
4. The large caliber interval terminals, can install a maximum 6mm ² wire.
5. Electronic protection load output, and is not afraid of a short circuit overload,

full protection, guaranteed not to damage the machine parts.
6. Four load operating modes: pure light control, light control timing manually

debug mode.
7. Series PWM charging main circuit, the charging efficiency is greatly improved,

more perfect battery protection function.
8. Board design dustproof, moisture-proof, anti-vibration, anti-high temperature,

anti-bottom temperature. Super harsh environments, the general plant products

do not have so powerful.
9 .Dimensions: 133 X 70 (mm) mounting hole dimensions: 126 X 50 (mm)

Installtion&Operation
* Controller connected with battery:choose suitables to make the terminal of back panel"BAT+","BAT-"connect with the positive and negative elecrode of battery separately,confirm the polarity connection is connnect.Then the "BATTERY"indicative light of controller panel is gree otherwise,check the wire connection and if cables damaged or not.

* Controller connected with solar components:chosse suitbale cables to make the nof solar cells connect with negative of battery;the positive of solar cells connect the positive of terminal of back panel SOL+ (follows the page CH-8).Egative

* Controller connected with DC loads:choose suitable cables make the positive of loading connect with the positive of battery;the negative of loading connect with the terminal of back panel LOAD- (follws the page CH-8).
